FCR Capsula X

FCR Capsula X
FCR Capsula X
Product Code : 01
Product Description

Our precious customers can avail from us optimum quality FCR Capsula X that means a small box. It processes 43-72 images per hour and is apt for less volume areas with low demanding workflow. This box is manufactured utilizing supreme grade raw material and is designed by our vendors with high precision. We offer this FCR Capsula X in various shapes, sizes and designs and can be purchased by our clients at affordable rates.

Features:

  • Rigid design

  • Smooth edges

  • Optimum strength

  • Durability



Standard Components
  • FCR capsula X image reader (Model: CR-IR 357)
  • AC power coad
Other system components
  • IP cassette type CC, LC
  • CR console
  • Image recorder: Drypix 1000/300/4000/7000

SuppliesImaging Plate
ST-VI


14" x 17" , 14" x 14", 10" x 12", 8" x 10", 15 x 30cm (Inch settings)
35 x 43 cm, 35 x 35cm, 24 x 30cm, 18 x 24 cm, 15 x 30 cm (Metric settings)

IP Cassette Type CC


14" x 17" (35.4 x 43 cm), 14" x 14" (35.4 x 35.4 cm), 10" x 12", 8" x 10", 24 x 30cm, 18 x 24 cm, 15 x 30cm

Type LC


35.4 x 124.5cm, 35.4 x 101.7 cm, 35.4 x 83 cm, 25.2 x 58 cm, 24 x 57cm

Time Required for IP Feed / Load

IP Type
Required Time
14" x 17" (35 x 43 cm) Approx. 82 sec.
14" x 14" (35 x 43 cm) Approx. 72 sec.
10" x 12"
Approx. 66 sec.
8" x 10"
Approx. 53 sec.
24 x 30 cm
Approx. 66 sec.
18 x 24 cm
Approx. 50 sec.
15 x 30 cm
Approx. 65 sec.

  • The time required for changing the cassette is assumed to be 0 (zero) seconds.
  • The time required for image erasure is assumed to be for exposure performed at 25mR of X-ray dose.
Processing Capacity
IP Type
When connected to
Drypix 7000/CR Console Pluse
14" x 17" (35 x 43 cm)
Approx. 43 IPs/hr.
14" x 14" (35 x 35 cm) Approx. 50 IPs/hr.
10" x 12"
Approx. 54 IPs/hr.
8" x 10"
Approx. 67 IPs/hr.
24 x 30 cm (ST)
Approx. 54 IPs/hr.
18 x 24 cm (ST)
Approx. 72 IPs/hr.
15 x 30 cm (ST)
Approx. 55 IPs/hr.

  • The time required for changing the cassette is assumed to be 0 (zero) seconds
  • The time required for image erasure is assumed to be for exposure performed at 25 mR of X-ray dose.
Time to print on Drypix 7000 through network via CR Console
Approx. 135 sec. (35 x 43 cm).

Time To Display on CR Console
  • 35 x 43 cm: Approx. 52 sec.
  • 18 x 24 cm: Approx. 31 sec.
  • Number of Stackers: 1
  • Reading gray scale: 12 bits
  • Network: 10 Base T /100 Base TX
  • Dimensions (W x D x H): 590 x 380 x 810 mm (23" x 15" x 32")
  • Weight: 99 kg (218 Ibs.)
  • Power Supply Conditions
    • Single phase 50-60Hz
    • 120-240V ±10%
    • 5A (max).
Environmental Conditions
  • Operating Conditions
    • Temperature: 16-30°C
    • Humidity: 15-80%RH (No dew condensation)
  • Non-operating conditions
    • Temperature: 0.45°C
    • Humidity: 10-90%RH (No dew condensation).
